The following image I found online. From what I can tell it is correct. Note that the cab seats rotate to face the main area. Sofa behind driver’s seat has been replaced with two custom leathers seats that match other interior. There also is a custom matching table. They face a TV that rises up from behind the sofa behind the passenger’s seat.
The information in the following tables is based on the window sticker as well as paperwork stored in the cab. Please verify.
Description
| Make: | Itasca Ellipse | |
| Model: | 2011 IKR40CD | |
| Engine: | Upgraded 450HP Cummins Engine with DEF System | |
| Mileage: | Less than 90k |
Dimensions
| Exterior Length: | 40’7″ |
| Exterior Width: | 101″ |
| Exterior Height: | 12’9″ |
Capacities
| Fuel: | 100 Gallons |
| Fresh Water: | 90 Gallons |
| Holding tank – black: | 54 Gallons |
| Holding tank – gray: | 117 Gallons |
| LPG (Fillable to 80%): | 30 Gallons |
A few years ago the refrigerator was replaced. The windshield was replaced at the same time, since it had a crack from a rock strike.
Documents
We have the following manuals:
Other documents in the file folders listed below. Note that I have not confirmed that this is the current equipment in the vehicle. I have no reason to think it isn’t correct, but these need to be verified. The paper files include:
- A Whirlpool Side by Side Refrigerator User Guide. We will verify if this is for the new one.
- A Rand McNally RVGPS manuals
- Installation Instructions and User Guides for a Fisher&Paykel DishDrawer dishwasher
- Dirt Devil CV1500 High Performance Central Cleaning System Owner’s Manual
- Thetford Build-in Cooking HOB User and Installation Instructions
- Shinybow Component Video/Audio Switcher – SB-5470 Matrix Switcher Instruction Manual
- Demco Self-aligning Tow Bar Commander 2 Operator Manual
- Dish Playmaker Antenna/Dish Playmaker Dual Antenna Instruction Manual
- Installation Instructions and Owner’s Manual – Counter Depth Side by Side Refrigerator (03/18 print date)
- SeriusXM XSG2NA-X2 Infotainment Center Owner’s Manual
- ME-MR25 Functions Card from Magnum Energy
- Cummins Onan User Guide Card
- Kenmore Elite Microwave Hood Combination Use & Care Guide Model 790.8036
- Kenmore Elite Microwave Oven Control Panel Features Card
- e-ASK electronic Access Security Keyless-entry Installation Instructions
Receipts & Invoices
- Invoice for 8 Interstate Batteries dated 4/7/2021
- Invoice for 6 Michelin X Line Energy Z 16PLY tires dated 6/20/2018
- Date code on a tire I checked was 2018 – 20th week of 2018 would be May 14-20
- Invoices for Oil, filters (fuel, oil) with mileage notations. I have a few and will check his file cabinet at home to find the others. I personally was on the creeper lubing the suspension and swapping filters for the last one.
Still To Add Here
I have the window sticker with a lot of information still to enter here.
Some of the bullet points that need more details:
- Manufacturer options installed:
- 450hp 8.9L engine $12,446
- Entertainment center/ext TV-DVD $1,890
- Power Cord Reel $735
- Microwave/speedcook oven $553
- Lounge Chairs with table $525
- Infotainment Center/GPS $1813
- Residential Refrigerator Package (w/2.8k inverter & 2 batteries) $1372 (Note – refrigerator was recently replaced)
- Washer and Drier pair $1,750
- Dishwasher drawer style $1,155
- Central Vacuum System $378
- Compartment Tray Slideout $616
- Sofa/bed ultra leather $490
- Water supply hose w/ reel $399
- Seats cab heated $322
- Generator 10kw Onan Quiet Diesel w/ less than 400 hours $1,302
- Radio – satellite $350
- A/C Roof (3) 13,500BTU w/ Heat Pump
- Leveling Jacks-Hydraulic Automatic
- Trailer Hitch – 10,000lb draw bar
- Three slides
- King sized bed and a jackknife sofabed
- More to come!
Still to add:
- Generator Hours – less than 400 hours
- Check details on new refrigerator
- Bath and a half.
- Upload higher resolution photos.
